PM42-B90G LED hand sensor dimmer switch/adjust color temperature
price
$2.50 - $3.00 / piece
PM42-B90G
1 piece
Shenzhen
Quantity
- Warranty(Year):2-Year
- Lighting solutions service:auto CAD layout
- Place of Origin:Guangdong, China
- Brand Name:PIMI
- Type:MANUAL SWITCH
- Max. Load Power:36W
- Product name:Hand sensor dimmer switch
- Input Voltage:7-30V
- Output Voltage:7-30V
- Output Current:1000-3000mA
- Output power:36W max
- Dimming mode 1:continuous dimming
- Dimming mode 2:step dimming
PM42-B90G
Hand sensor dimmer switch/adjust color temperature
| model | input constant voltage | output constant voltage | output current | dimming mode | approval |
| PM42-B90G1000 | 7-30VDC | 7-30VDC | 1000mA | continuous dimming
step dimming
changing CCT | CE |
| PM42-B90G2000 | 7-30VDC | 7-30VDC | 2000mA | CE | |
| PM42-B90G3000 | 7-30VDC | 7-30VDC | 3000mA | CE | |
| PM42-B90G1000H | 27-60VDC | 27-60VDC | 1000mA | CE | |
| PM42-B90G2000H | 27-60VDC | 27-60VDC | 2000mA | CE | |
| PM42-B90G3000H | 27-60VDC | 27-60VDC | 3000mA | CE |
Induction distance: 3-15cm
Dimming mode: induction continuous dimming
4-stage induction dimming
dimmer and adjust color temperature
Dimensions(L*W*H): A: 50*17*10mm
B: 35*14*10mm
C: 65*14*6mm
Standards: EN 55015
EN 61000
EN 61547
EN 61058
